TZD-550-10B
trusTec
Nema 48
550W
300-1200RPM
200pcs
Negotiable (FOB/CNF/CIF)
Standard carton packing, foam board inside for protection.
T/T, L/C
15 days fresh products after order confirmation.
100,000 pcs per month
| Quantity: | |
|---|---|
| Product: | ECM Blower Motor | Frame: | Nema 48 |
| Motor Type: | Direct Drive Blower | Supply Voltage: | 220-240V |
| Enclosure Type: | OAO(Open Air Over) | Supply Frequency: | 50 / 60 HZ |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Current: | 4.5A |
| Phase: | Single Phase | Output Power | 550W |
| Mounting: | Round | Speed: | 300-1200RPM |
| Bearings: | Ball Bearing | Poles: | 10P |
| Mounting Orientation: | Stud Mounting All Angel | Shaft Diameter: | 1/2" / 12.7mm |
| Insulation Class: | Class F | Shaft Length: | 4.0" / 101.6mm |
| Rotation: | CW(SE) | Max. Ambient Temperature: | 40℃ / 104℉ |
| Speed Control: | 0-10V Speed Control/PWM | ||
Indoor ECM blower motors
In residential air conditioning: wall-mounted units, floor-standing units, and residential central air conditioning systems
In commercial air conditioning: office building central air conditioning systems, hotel-specific air conditioning systems, and muil-split systems for shopping malls
• All ECM blower motors from trusTec are manufactured by strictly following the ISO9001 management system
• 48 Frame blower motor enjoy at least 2 full years warranty since leaving the factory
• 100% replacement is guaranteed for any defect among the warranty period
• Our ECM blower motors have been approved by RoHS, CCC, CE and UL certificates
•Trustec ECM blower motors are 100% exported to American, Eurpoe, Mid-East, Asia, and have been approved by the global market
1.Trustec company is not only a quality and competitive products manufacturing & sales enterprise, but also a reliable solution supplier for customers around the world
2. We cooperate with customer to design and develop new product. Provide OEM
3. We are willing to help you arrange delivery, testing or other requests
4. From quick demand response, professional and high efficient following up, to helping optimize shipping & save cost, offering overseas technial support, Trustec will ensure customers the best matched ECM blowe motors, as well as the best service
The pricise price will be quoted after checking the specification and mounting dimension of the motor.
The warranty is 18 months on the production date, under the warranty we will aford the shipping cost to send the replacement.
Yes, we can offer the ODM.
By sea, by air, by courier(UPS, DHL, Fedex, TNT etc.)
Normally 15-30 days.
Normaly 3 days if we have the sample in hand. If customized one, about a week around.
No. our design team works with end users and OEMs to provide the lowest total life cycle cost solution. If continuous operation is criticl to your operation, our technologies can design and manufacturer motors based your specific or unique needs to avoid costly equipment down time.
