TZD-375-10A-UMG
trusTec
Nema 48
375W
500-2400RPM
200pcs
Negotiable (FOB/CNF/CIF)
Standard carton packing, foam board inside for protection.
T/T, L/C
15 days fresh products after order confirmation.
100,000 pcs per month
| Quantity: | |
|---|---|
| Product: | ECM Fan Coil Unit Motor | Frame: | 48 Frame |
| Enclosure Type: | TEAO (Toatlly Enclosed Air Over) | Supply Voltage: | 208-230V |
| Thermal Overload: | Equipped With An Automatic Thermal Overload | Supply Frequency: | 50 / 60 HZ |
| Phase: | Single Phase | Current: | 3.5A |
| Mounting: | Bracket | Output Power | 375W |
| Bearings: | Ball Bearing | Speed: | 500-2400RPM |
| Mounting Orientation: | All Angle | Poles: | 10P |
| Insulation Class: | Class B | Flat Length: | 4.72" / 120mm |
| Control Mode: | VSP | Shaft Length: | 14.63" / 371.5mm |
| Rotation: | CCW(LE) | Shaft Diameter: | 0.5" / 12.7mm |
| Max. Ambient Temperature: | 40 ℃ / 104℉ | Lead Length: | 19.69" / 500mm |
| Motor Shell Length: | 5.22" / 132.6mm | ||
This 375W ECM fan coil unit motor features a permanent magnet synchronous structure with built-in control module, enabling precise speed regulation to meet both high energy efficiency and comfort requirements of modern fan coil unit.
• Variable speed control: 500-2400RPM
• 375W output power for medium to high air volume demands
• High-eficiency operation for lower system energy consumption
• Low noise for improved indoor comfort
• Soft start design to extend system service life
Idea for a wide range of HVAC and air control scenarios, including:
• Fan coil units in commercial buildings
• Hotel guest room FCUs
• Hospital air conditioning and ventilation systems
• Office building HVAC systems
• Residential central air conditioning systems
All ECM blower motors from trusTec are manufactured by strictly following the ISO9001 management system.
48 Frame blower motor enjoy at least 2 full years warranty since leaving the factory.
100% replacement is guaranteed for any defect among the warranty period.
Our ECM blower motors have been approved by RoHS, CCC, CE and UL certificates.
Trustec ECM FCU motors are 100% exported to American, Eurpoe, Mid-East, Asia, and have been approved by the global market.
Original Equipemnt Manufacturer, Support Customization Service
Depending on trusTec Team's powerful designing and manufacturing ability, customers' special needs of the ECM motors, including performance and parameters and mounting dimensions, will be perfectly fulfilled
trusTec branded ECM moters are 100% exported to America, Europe, Mid-East, Asia, and have been approved by the global market
Our company is attending HVAC / R fairs held in China, Asia, Europe, Mid-East and America every year
The beneficial ODM co-operative relation will be warmly established with trust and loyalty
The pricise price will be quoted after checking the specification and mounting dimension of the motor.
The warranty is 18 months on the production date, under the warranty we will aford the shipping cost to send the replacement.
Yes, we can offer the ODM.
By sea, by air, by courier(UPS, DHL, Fedex, TNT etc.)
Normally 15-30 days.
Normaly 3 days if we have the sample in hand. If customized one, about a week around.
No. our design team works with end users and OEMs to provide the lowest total life cycle cost solution. If continuous operation is criticl to your operation, our technologies can design and manufacturer motors based your specific or unique needs to avoid costly equipment down time.
